BYD Qin PLUS EV Rear Fender Panel | Rear Quarter Panel OEM Spec
All Category
Contact Us
Mrs. zhang
18631122230
wechat
18631122230
Chat Now

BYD Qin PLUS EV Rear Fender Panel | Rear Quarter Panel OEM Spec

Brand Name: BYD
Model Number: BYD Qin PLUS EV
MOQ: 1
Price: Negotiable
Payment Terms: L/C
Detail Information
Charging Time (Fast Charge):
30 Minutes (80% Charge)
Drive Type:
Front-Wheel Drive
Infotainment System:
12.8-inch Rotating Touchscreen With DiLink OS
Electric Range (Nedc):
506 Km
Wheelbase:
2770 Mm
Model:
BYD Qin PLUS EV
Torque:
210 Nm
Vehicle Type:
Electric Sedan
Motor Power:
135 KW
Battery Type:
Blade Battery
Seating Capacity:
5
Dimensions (L×W×H):
4760 × 1837 × 1495 Mm
Battery Capacity:
60.48 KWh
Acceleration (0-100 Km/H):
7.3 Seconds
Motor Type:
Permanent Magnet Synchronous Motor
Product Description

This product is specifically designed for the rear body of the BYD Qin PLUS EV (including Champion Edition and Intelligent Driving Edition). It is a core body panel that forms the streamlined rear side profile of the vehicle—the rear fender panel. Acting as the "side wing profile" of the vehicle body, the rear fender extends from the rear door gap to the taillight area, covering the space above the rear wheel. Together with the front fender, it shapes the smooth side lines of the vehicle. As an integral part of the body-in-white side panel, the rear fender not only determines the visual aesthetics of the rear side but also performs multiple functions including covering the rear wheel, blocking mud splash, and guiding airflow, making it a key exterior component integrating aesthetics, aerodynamics, and structural rigidity.

As a core sales model of BYD's pure electric vehicle lineup, the BYD Qin PLUS EV is available in multiple range versions including 420KM, 510KM, and 610KM, with body dimensions of 4765-4795mm × 1837mm × 1515mm and a wheelbase of 2718mm. The Qin PLUS series generally uses 73.5% high-strength materials, and as an integral part of the body side panel, the structural strength and corrosion resistance of the rear fender directly affect the safety and durability of the vehicle.

Important Note: The rear fender is integrated with the rear side panel, welded together with structural components such as the A/B/C pillars and roof cross members. Therefore, the rear fender cannot be removed independently. In the event of severe damage (such as collision deformation or large-area corrosion perforation), repair typically requires cutting and replacing the damaged section, which must be performed by a qualified body repair technician in a professional repair shop.
